EGN Single phase Drainage Pump for Clean Water

NEW
EGN Single phase Drainage Pump for Clean Water
  Zoom
 EGN Single phase Drainage Pump for Clean WaterEGN Single phase Drainage Pump for Clean Water
Our Price:  CALL US: +44(0)1473 462046(Exc. 20% VAT)
+
Pump:

Part Number:  EGN 4
Brand:  Franklin Electric E-tech
Max Flow:  500 m3/h
Max Head:  20 m
Series:  EGN Series
Phase:  Single Phase

Franklin Electric E-tech

Franklin Electric E-tech ED Series Single Phase Stainless steel Drainage submersible pumps for dirty water.

Franklin Electric E-tech EGN Series Single Phase Stainless steel Drainage submersible pumps for clean water.

Construction

  • Single-impeller submersible drainage pump, with open impeller with vertical threaded delivery port (G 1 1/2)
  • Double mechanical shaft seal with interposed oil chamber, to protect against dry-running

Applications

  • For clean containing solids up to 10 mm grain size
  • For draining rooms or or emptying tanks
  • Extraction of water from ponds, streams or pits and for rainwater collection

Operating Conditions

  • Liquid temperature: up to 35 °C
  • Maximum immersion depth: 5 m
  • Minimum immersion depth: 205 mm
  • Continuous duty (with submerged motor)

Motor Specification (EGN Single and Three Phase)

  • 2-pole induction motor, 50 Hz (n ≈ 2900 rpm)
  • EGNT:
  • Three-phase 230 V ± 10 %; Three-phase 400 V ± 10 %
  • Cable: H07Rn-F, 4G1 mm², length 10 m, without plug
  • EGN:
  • Single-phase 230 V ± 10 %, with float switch and thermal protector
  • Incorporated capacitor
  • Cable: H07Rn-F, 3G1 mm2, length 10 m, with plug CeI-UneL 47166
  • Insulation class F
  • Protection Ip X8 (for continuous immersion)
  • Triple impregnation humidity-proof dry winding
  • Constructed in accordance with: EN 60034-1; EN 60335-1, EN 60335-2-41

Available on Request

  • Other voltages
  • Frequency 60 Hz
  • Other mechanical seal
  • Cable length 20 m
  • Vertical magnetic float switch
  • Motor suitable for operation with frequency converter
  • Three-phase pumps with incorporated float switch

Product and technical Sheets

  Click here to download
